Features:
- Indoor Use - These standard-grade single wall vertical tanks are rotationally molded with no seam and are constructed to store DEF with a specific gravity of 1.35 providing maximum strength and durability for long-term trouble-free use.
- Large Capacities - A variety of tank dimensions are available for filling drums, totes, or transports (see Snyder sizing below)
- Bottom Fill & Withdrawal - Supplied with Stainless Steel bottom tank outlets & lockable valves to improve the tank's structural integrity and provide the best long-term solution
- Tank Warranty - 3-year material & workmanship
Tank Specifications:
- HDLPE Polyethylene Single Wall Flat-Bottom
- Built to Commercial Specification for DEF
- Long-term UV-15 Stabilizer
- Natural Color White
- FOB - St. Bonifacius MN
Plumbing Specifications:
- 3" FNTP Stainless Steel Tank Outlet with Siphon Tube
- Tank Outlet Package with 2" Stainless Steel Full Port Lockable Valve
- 3" Tank 10-Micron Breather Vent
- 18" Non-Vented Manway to Protect Product Integrity
- 2x additional 2" Openings on Top of Tank Self Aligning
Construction Specifications:
- Tank Wrap for shipping on tanks 3,000g or less
- On-Site Assembly Required. Instructions Included with shipment.
Norwesco Tank Sizes - Dimensions (Diameter x Height / Tip to Vert Clearance)
***Dimensions may vary /- 3% due to standard rotational molding tolerances
- KBS N3000SWD95 - 3,000g (95" x 109" / 145")
- KBS N3000SWD - 3,000g (102" x 93 / 140")
- KBS N5000SWD - 5,000g (102" x 152" / 183")
- KBS N6000SWD - 6,000g (102" x 182" / 210")
- KBS N6500SWD - 6,500g (119" x 150" / 192")
- KBS N7800SWD - 7,800g (119" x 176" / 213")
- KBS N9000SWD - 9,000g (141" x 146" / 204")
- KBS N10000SWD - 10,000g (141" x 160" / 214")
- KBS N12000SWD - 12,000g (141" x 193" / 239")
- KBS N15000SWD - 15,000g (165" x 186" / 248")
Miscellaneous Parts
- SBD 910381 - Parker 2" Male Stainless Steel Drybreak
